Product Details:
|
| Display: | 7 Inch LCD | Salinity: | (0 ~ 100) Ppt |
|---|---|---|---|
| Resolution: | 0.01/0.1/1 μS/cm 0.01/0.1/1 MS/cm | Resistivity: | (0 ~ 100) MΩ*cm |
| Temperature Accuracy: | 5-60℃: ±0.5℃, Others: ±1.0℃ | Temperature Range: | 0℃~100℃ |
| Temperature Compensation: | 0~100℃ | IP Grade: | IP54 |
| Communication: | USB | Type: | Bench Conductivity Meter |
Product Name | Conductivity Meter |
Origin | China |
Brand | PEAK INSTRUMENTS |
Model | T-711P |
Display | 7 inch LCD |
Electrode constant | 0.1/1/10cm-1 |
Temperature range | 0℃~100℃ |
Temperature compensation | 0~100℃ |
Temperature accuracy | 5-60℃: ±0.5℃, Others: ±1.0℃ |
Communication | USB |
Calibration | 1 point |
Resolution | 0.01/0.1/1 μS/cm 0.01/0.1/1 mS/cm |
Accuracy | Electrode: ±1.0% FS, Instrument: ±1.50%FS |
Conductivity range | (0.00~20.00) μS/cm (20.0~200.0) μS/cm (200~2000) μS/cm (2.00~20.00) mS/cm (20.0~200.0) mS/cm |
Data storage | 1000 sets |
Storage content | Measurement series number, measuring value, temperature, ATC or MTC status, date and time |
Power | DC12V/1A |
Communication | Wireless Bluetooth, USB |
Dimensions & Weight | 240×170×70mm/600g |
Ambient temperature | 5 ~ 35 ℃ |
Ambient humidity | ≤85% |
IP grade | IP54 |
1. Assemble main board | 2. Connect lines for main board | 3. Prepare device housing | 4.Assemble core board on main board |
5.Install main board on the frame | 6. Install display screen on front frame |
7.Upload software | 8. Install electrode connectors | 9. Connect mainboard and display board | 10. Housing installation and calibration |
Office and workshop buildings, factory was built up in 2006 | ||||||||
